VRTK.Unity.Core

A collection of design patterns for solving common problems

Introduction

VRTK.Unity.Core is a collection of design patterns for the Unity software that can be beneficial in (but not limited to) spatial computing development.

VRTK.Unity.Core requires Unity3d 2018.3 (or above).

Getting Started

Setting up a project

• Using the Unity software version 2018.3 (or above), create a new project using the 3D Template or open an existing project.
• If the project supports Virtual Reality:
  • Ensure Virtual Reality Supported is checked.
    • In Unity3d select Main Menu -> Edit -> Project Settings to open the Project Settings window.
    • Select Player from the left hand menu in the Project Settings window.
    • In the Player settings panel expand XR Settings.
    • In XR Settings ensure the Virtual Reality Supported option is checked.
  • Ensure the appropriate support package is installed.
    • In Unity3d select Main Menu -> Window -> Package Manager to open the Packages window.
    • Find the appropriate support package in the left hand menu and click on it to select it (e.g. Oculus (Standalone) or OpenVR).
    • Click the Install button in the right hand pane of the Packages window for the selected support package.
    • The package will now install and be available for your supported hardware.
• Ensure the project Scripting Runtime Version is set to .NET 4.x Equivalent.
  • In Unity3d select Main Menu -> Edit -> Project Settings to open the Project Settings inspector.
  • Select Player from the left hand menu in the Project Settings window.
  • In the Player settings panel expand Other Settings.
  • Ensure the Scripting Runtime Version is set to .NET 4.x Equivalent.

Cloning the VRTK.Unity.Core repo into a project

• Navigate to the Assets/ directory of your project.
• Git clone this repo into the Assets/ directory:
  • git clone https://github.com/ExtendRealityLtd/VRTK.Unity.Core.git - How To Clone A Repo
• Wait for Unity3d to finish importing the cloned files.

Contributing

We’re not currently in a place where accepting contributions would be helpful. But as soon as we’re ready we’ll let you know!

License

Code released under the MIT License.

Disclaimer

These materials are not sponsored by or affiliated with Unity Technologies or its affiliates. “Unity” is a trademark or registered trademark of Unity Technologies or its affiliates in the U.S. and elsewhere.
